Introduction
This v shape dry powder mixer machine is used for mixing two or more dry power or granule raw materials from pharmaceutical industry, chemical industry, foodstuff industry and so on. The powder mixer has several different capacity. Please tell your request for the dry powder mixer machine, we can recommend suitable model for you.
Advantage
The powder mixer machine structure is unique. The mixing machine can mix material together evenly and no dead corner.
The V shape dry powder mixer is made of stainless steel 304 material . the mixer inner and outer walls are polished well.so the mixing machine looks very nice and high quality. And mixing efficiency is very high and very even.
The mixing stirrer can be installed base on customer’s request for special material.such as pretty fine powder, cake and certain moist stuff.
Technical parameters
Model |
VH-0.05 |
VH-0.1 |
VH-0.3 |
VH-0.5 |
VH-1.0 |
VH-1.5 |
VH-2.0 |
VH-2.5 |
VH-33 |
Total volume(L) |
50 |
100 |
300 |
500 |
1000 |
1500 |
2000 |
2500 |
3000 |
Max working volume(L) |
20 |
40 |
120 |
200 |
400 |
600 |
800 |
1000 |
1200 |
Stiring speed(R/M) |
12 |
12 |
12 |
12 |
12 |
12 |
12 |
12 |
12 |
Power of motor(KW) |
0.37 |
0.55 |
1.1 |
1.5 |
2.2 |
3 |
4 |
5.5 |
7.5 |
Rotating height(mm) |
1300 |
1500 |
1900 |
2500 |
2700 |
2900 |
3250 |
3800 |
3850 |
Weight(kw) |
55 |
100 |
350 |
550 |
900 |
1100 |
1500 |
1700 |
1800 |
Outlet Diameter(mm) |
80 |
80 |
100 |
150 |
150 |
200 |
200 |
200 |
200 |
